IslandPathversion 1.0

IslandPath Analysis: Yersinia pestis Pestoides F



Each circle in the graphic corresponds to a predicted protein-coding ORF in the genome. Circle colours indicate if an ORF has a higher or lower %G+C than cutoffs you set below --(default is +/- 3.48 of the mean %G+C). Strike lines across the circles represent regions with dinucleotide bias above a pre-determined cutoff. Click on a circle to view a different portion of the table presented below the graph (default is the first 100 ORFs).
A yellow circle indicates its %G+C value is bigger than the high value. A green circle indicates its %G+C value is bigger than the low value and smaller than the high value. A pink circle indicates its %G+C value is smaller than the low value. A strike line across the circles indicates the region has dinucleotide bais above 1 STD DEV. A black verticle bar indicates a transfer RNA gene lies between the two ORFs. A purple verticle bar indicates a ribosomal RNA gene lies between the two ORFs. A deep blue verticle bar indicates both a tRNA and rRNA gene lie between the two ORFs. A black square indicates the dot is annotated as a transposase. A black triangle indicates the dot is annotated as an integrase. Low: High: Mean: 48.06 STD DEV: 4.80
Yersinia pestis Pestoides F, complete genome - 1..4517345
3850 proteins
Pos	%G+C	SD	Location	Strand	Length	PID	Gene	Synonym	Code	Product
1689	 40.79	-1	1946695..1947405	+	236	145599012	-	YPDSF_1730	-	hypothetical protein
1690	 48.09	0	1947975..1948523	+	182	145599013	-	YPDSF_1731	-	hypothetical protein
1691	 47.20	0	1948727..1950118	+	463	145599014	-	YPDSF_1732	-	transport protein
1692	 48.24	0	1950333..1951184	-	283	145599015	-	YPDSF_1733	-	N-acetylmuramoyl-L-alanine amidase
1693	 44.19	0	1951569..1952360	-	263	145599016	-	YPDSF_1734	-	IclR family transcriptional regulator
1694	 45.93	0	1952547..1953713	-	388	145599017	-	YPDSF_1735	-	oligogalacturonate lyase
1695	 51.24	0	1954040..1955407	+	455	145599018	-	YPDSF_1736	-	transport protein
1696	 48.26	0	1955461..1956264	-	267	145599019	-	YPDSF_1737	-	chaperone protein
1697	 46.13	0	1956261..1957424	-	387	145599020	-	YPDSF_1738	-	fimbrial protein
1698	 49.37	0	1957421..1960033	-	870	145599021	-	YPDSF_1739	-	outer membrane usher protein
1699	 44.10	0	1960115..1960894	-	259	145599022	-	YPDSF_1740	-	chaperone protein
1700	 42.54	-1	1961047..1961589	-	180	145599023	-	YPDSF_1741	-	fimbrial protein
1701	 47.05	0	1962247..1963128	-	293	145599024	-	YPDSF_1742	-	heat shock protein HtpX
1702	 47.23	0	1963583..1965655	-	690	145599025	-	YPDSF_1743	-	carboxy-terminal protease
1703	 52.80	0	1965675..1966388	-	237	145599026	-	YPDSF_1744	-	putative solute/DNA competence effector
1704	 45.18	0	1966484..1966981	-	165	145599027	-	YPDSF_1745	-	hypothetical protein
1705	 49.96	0	1967108..1968460	+	450	145599028	-	YPDSF_1746	-	hypothetical protein
1706	 49.74	0	1968429..1971080	+	883	145599029	-	YPDSF_1747	-	hypothetical protein
1707	 46.67	0	1971560..1972114	+	184	145599030	-	YPDSF_1748	-	hypothetical protein
1708	 49.72	0	1972120..1972650	+	176	145599031	-	YPDSF_1749	-	hypothetical protein
1709	 46.77	0	1972671..1973228	+	185	145599032	-	YPDSF_1750	-	hypothetical protein
1710	 44.62	0	1973259..1974011	+	250	145599033	-	YPDSF_1751	-	chaperone protein
1711	 46.12	0	1974199..1976646	+	815	145599034	-	YPDSF_1752	-	outer membrane usher protein
1712	 42.22	-1	1976852..1977841	+	329	145599035	-	YPDSF_1753	-	hypothetical protein
1713	 40.83	-1	1978049..1978288	+	79	145599036	-	YPDSF_1754	-	hypothetical protein
1714	 47.95	0	1978398..1978787	-	129	145599037	-	YPDSF_1755	-	hypothetical protein
1715	 45.24	0	1979055..1979180	+	41	145599038	-	YPDSF_1756	-	hypothetical protein
1716	 52.79	0	1979194..1980216	+	340	145599039	-	YPDSF_1757	-	transposase for insertion sequence IS100
1717	 50.38	0	1980216..1980995	+	259	145599040	-	YPDSF_1758	-	transposase/IS protein
1718	 48.13	0	1981946..1983202	-	418	145599041	-	YPDSF_1759	-	lipoprotein
1719	 43.78	0	1983595..1983843	-	82	145599042	-	YPDSF_1760	-	hypothetical protein
1720	 45.04	0	1984990..1986219	+	409	145599043	-	YPDSF_1761	-	alanine racemase
1721	 41.61	-1	1986838..1987791	-	317	145599044	-	YPDSF_1762	-	hypothetical protein
1722	 58.06	+2	1987891..1988436	-	181	145599045	-	YPDSF_1763	-	surface protein
1723	 58.16	+2	1988312..1990522	-	736	145599046	-	YPDSF_1764	-	hypothetical protein
1724	 41.70	-1	1990879..1991643	-	254	145599047	-	YPDSF_1765	-	N-acetylmuramoyl-L-alanine amidase
1725	 37.50	-2	1991775..1991894	+	39	145599048	-	YPDSF_1766	-	hypothetical protein
1726	 48.99	0	1992214..1992858	-	214	145599049	-	YPDSF_1767	-	chemotaxis regulator CheZ
1727	 45.90	0	1992868..1993257	-	129	145599050	-	YPDSF_1768	-	chemotaxis regulatory protein CheY
1728	 53.23	+1	1993417..1994406	-	329	145599051	-	YPDSF_1769	-	protein-glutamate methylesterase
1729	 50.23	0	1994406..1995293	-	295	145599052	-	YPDSF_1770	-	chemotaxis methyltransferase CheR
1730	 50.90	0	1995451..1997061	-	536	145599053	-	YPDSF_1771	-	hypothetical protein
1731	 48.03	0	1997245..1998918	-	557	145599054	-	YPDSF_1772	-	methyl-accepting chemotaxis protein
1732	 45.07	0	1999159..1999797	-	212	145599055	-	YPDSF_1773	-	hypothetical protein
1733	 51.20	0	1999929..2002805	-	958	145599056	-	YPDSF_1774	-	integral membrane protein
1734	 53.11	+1	2003333..2007139	-	1268	145599057	-	YPDSF_1775	-	hypothetical protein
1735	 37.09	-2	2007614..2008279	-	221	145599058	-	YPDSF_1776	-	putative DNA-binding protein
1736	 43.06	-1	2008469..2009455	+	328	145599059	-	YPDSF_1777	-	hypothetical protein
1737	 41.80	-1	2009452..2009829	+	125	145599060	-	YPDSF_1778	-	YjgF-family lipoprotein
1738	 43.53	0	2009842..2011077	+	411	145599061	-	YPDSF_1779	-	membrane protein
1739	 47.39	0	2011369..2011866	-	165	145599062	-	YPDSF_1780	-	purine-binding chemotaxis protein
1740	 50.18	0	2012029..2014194	-	721	145599063	-	YPDSF_1781	-	chemotaxis protein CheA
1741	 48.92	0	2014211..2015512	-	433	145599064	motB	YPDSF_1782	-	flagellar motor protein MotB
1742	 48.42	0	2015509..2016396	-	295	145599065	-	YPDSF_1783	-	flagellar motor protein MotA
1743	 48.11	0	2016601..2017182	-	193	145599066	-	YPDSF_1784	-	transcriptional activator FlhC
1744	 37.21	-2	2017280..2017537	-	85	145599067	-	YPDSF_1785	-	hypothetical protein
1745	 46.74	0	2018725..2021424	-	899	145599068	-	YPDSF_1786	-	Mg(2+) transport ATPase protein B
1746	 47.93	0	2021825..2022523	-	232	145599069	-	YPDSF_1787	-	Mg(2+) transport ATPase protein C
1747	 47.80	0	2023649..2024968	+	439	145599070	-	YPDSF_1788	-	hypothetical protein
1748	 49.35	0	2024922..2025383	+	153	145599071	-	YPDSF_1789	-	methyl-accepting chemotaxis protein III (MCP-III
1749	 48.96	0	2025566..2025757	-	63	145599072	-	YPDSF_1790	-	hypothetical protein
1750	 46.01	0	2025972..2026184	-	70	145599073	-	YPDSF_1791	-	cold shock protein
1751	 49.89	0	2026725..2029907	+	1060	145599074	lacZ	YPDSF_1792	-	beta-D-galactosidase
1752	 50.45	0	2030314..2031324	+	336	145599075	-	YPDSF_1793	-	Zinc-binding dehydrogenase
1753	 35.58	-2	2031607..2032140	+	177	145599076	-	YPDSF_1794	-	hypothetical protein
1754	 44.23	0	2032228..2032383	+	51	145599077	-	YPDSF_1795	-	hypothetical protein
1755	 44.22	0	2032646..2033095	+	149	145599078	-	YPDSF_1796	-	transcription regulator AsnC
1756	 47.67	0	2033187..2034086	+	299	145599079	-	YPDSF_1797	-	hypothetical protein
1757	 46.08	0	2034389..2034592	+	67	145599080	-	YPDSF_1798	-	hypothetical protein
1758	 48.79	0	2034894..2036219	-	441	145599081	-	YPDSF_1799	-	phosphoanhydride phosphorylase
1759	 40.86	-1	2036431..2036523	+	30	145599082	-	YPDSF_1800	-	hypothetical protein
1760	 53.85	+1	2036520..2036714	-	64	145599083	-	YPDSF_1801	-	hypothetical protein
1761	 48.53	0	2036751..2037158	-	135	145599084	-	YPDSF_1802	-	hypothetical protein
1762	 50.82	0	2037294..2038151	+	285	145599085	-	YPDSF_1803	-	hypothetical protein
1763	 50.22	0	2039071..2040651	+	526	145599086	-	YPDSF_1804	-	methyl-accepting chemotaxis protein
1764	 45.98	0	2040771..2041031	+	86	145599087	-	YPDSF_1805	-	hypothetical protein
1765	 49.14	0	2041307..2042350	+	347	145599088	-	YPDSF_1806	-	LacI family sucrose operon repressor
1766	 46.01	0	2042496..2043749	-	417	145599089	-	YPDSF_1807	-	isocitrate dehydrogenase
1767	 49.28	0	2043880..2044506	+	208	145599090	-	YPDSF_1808	-	pseudouridine synthase
1768	 49.44	0	2044499..2044945	+	148	145599091	-	YPDSF_1809	-	hypothetical protein
1769	 49.91	0	2045132..2046247	+	371	145599092	trmU	YPDSF_1810	-	tRNA (5-methylaminomethyl-2-thiouridylate)-methyltransferase
1770	 51.20	0	2046305..2046931	+	208	145599093	-	YPDSF_1811	-	hypothetical protein
1771	 47.56	0	2046992..2048362	+	456	145599094	-	YPDSF_1812	-	adenylosuccinate lyase
1772	 44.07	0	2048550..2049173	+	207	145599095	-	YPDSF_1813	-	lipoprotein
1773	 48.07	0	2049384..2050055	+	223	145599096	-	YPDSF_1814	-	DNA-binding transcriptional regulator PhoP
1774	 46.19	0	2050061..2051515	+	484	145599097	-	YPDSF_1815	-	sensor protein PhoQ
1775	 48.30	0	2051545..2052720	+	391	145599098	-	YPDSF_1816	-	hypothetical protein
1776	 45.31	0	2053141..2054376	-	411	145599099	-	YPDSF_1817	-	peptidase T
1777	 48.15	0	2054706..2055542	-	278	145599100	-	YPDSF_1818	-	NAD-dependent deacetylase
1778	 51.79	0	2055591..2055758	-	55	145599101	-	YPDSF_1819	-	hypothetical protein
1779	 50.58	0	2055736..2056506	-	256	145599102	-	YPDSF_1820	-	N-acetyl-D-glucosamine kinase
1780	 48.96	0	2056525..2057772	-	415	145599103	-	YPDSF_1821	-	outer membrane-specific lipoprotein transporter subunit LolE
1781	 49.36	0	2057772..2058476	-	234	145599104	lolD	YPDSF_1822	-	lipoprotein transporter ATP-binding subunit
1782	 52.04	0	2058469..2059671	-	400	145599105	-	YPDSF_1823	-	outer membrane-specific lipoprotein transporter subunit LolC
1783	 51.23	0	2059941..2063387	+	1148	145599106	-	YPDSF_1824	-	transcription-repair coupling factor
1784	 49.44	0	2063626..2064165	-	179	145599107	-	YPDSF_1825	-	hypothetical protein
1785	 49.63	0	2064495..2065703	-	402	145599108	-	YPDSF_1826	-	transposase for the IS285 insertion element
1786	 32.61	-2	2065799..2066212	-	137	145599109	-	YPDSF_1827	-	hypothetical protein
1787	 39.67	-1	2066220..2066708	-	162	145599110	-	YPDSF_1828	-	hypothetical protein
1788	 39.49	-1	2066962..2067156	-	64	145599111	-	YPDSF_1829	-	hypothetical protein
48.06	MEAN

4.80	STD DEV
