IslandPath Analysis: Xanthomonas oryzae pv. oryzae KACC10331



Each circle in the graphic corresponds to a predicted protein-coding ORF in the genome.
Circle colours indicate if an ORF has a higher or lower %G+C than cutoffs you set below
--(default is +/- 3.48 of the mean %G+C).
Strike lines across the circles represent regions with dinucleotide bias above a pre-determined cutoff.
Click on a circle to view a different portion of the table presented below the graph (default is the first 100 ORFs).




A yellow circle indicates its %G+C value is bigger than the high value.
A green circle indicates its %G+C value is bigger than the low value and smaller than the high value.
A pink circle indicates its %G+C value is smaller than the low value.

A strike line across the circles indicates the region has dinucleotide bais above 1 STD DEV.
A black verticle bar indicates a transfer RNA gene lies between the two ORFs.
A purple verticle bar indicates a ribosomal RNA gene lies between the two ORFs.
A deep blue verticle bar indicates both a tRNA and rRNA gene lie between the two ORFs.
A black square indicates the dot is annotated as a transposase.
A black triangle indicates the dot is annotated as an integrase.


Low:  High:    Mean: 63.81   STD DEV: 3.50
Xanthomonas oryzae pv. oryzae KACC10331, complete genome - 1..4941439
4144 proteins
Pos	%G+C	SD	Location	Strand	Length	PID	Gene	Synonym	Code	Product
3312	 64.35	0	3954006..3955214	+	402	161898966	kbl	XOO3691	-	2-amino-3-ketobutyrate coenzyme A ligase
3313	 67.94	+1	3955560..3956420	-	286	58583316	-	XOO3693	-	pseudouridylate synthase
3314	 67.45	+1	3956440..3956949	-	169	58583317	-	XOO3694	-	hypothetical protein
3315	 61.11	0	3957682..3958239	-	185	58583319	mopB	XOO3696	-	outer membrane protein
3316	 64.81	0	3958655..3959677	+	340	58583320	-	XOO3697	-	oxidoreductase
3317	 66.47	0	3959885..3961924	+	679	58583321	fadH	XOO3698	-	2,4-dienoyl-CoA reductase
3318	 66.52	0	3962023..3963393	+	456	58583322	-	XOO3699	-	hypothetical protein
3319	 63.17	0	3964000..3964485	+	161	58583324	-	XOO3701	-	IS1404 transposase
3320	 57.86	-1	3966483..3966902	+	139	58583330	-	XOO3707	-	putative transposase
3321	 58.70	-1	3966868..3967344	+	158	58583331	-	XOO3708	-	putative transposase
3322	 64.62	0	3967341..3968171	+	276	58583332	torS	XOO3709	-	two-component system sensor protein
3323	 64.14	0	3968159..3968632	+	157	58583333	-	XOO3710	-	two-component system regulatory protein
3324	 66.67	0	3968747..3969001	-	84	58583334	-	XOO3711	-	hypothetical protein
3325	 67.13	0	3968985..3969626	-	213	58583335	gst	XOO3712	-	glutathione S-transferase
3326	 64.54	0	3970031..3971770	+	579	58583336	glnS	XOO3713	-	glutaminyl-tRNA synthetase
3327	 58.01	-1	3972198..3972740	-	180	58583337	reut4275	XOO3714	-	IS30 family transposase
3328	 54.81	-2	3973204..3973650	-	148	58583339	-	XOO3716	-	transposase
3329	 58.91	-1	3974197..3974673	-	158	58583340	-	XOO3717	-	putative transposase
3330	 58.54	-1	3974639..3974995	-	118	58583341	-	XOO3718	-	putative transposase
3331	 66.19	0	3975155..3975364	-	69	121632129	-	XOO4903	-	hypothetical protein
3332	 68.80	+1	3975499..3976200	+	233	58583342	-	XOO3719	-	integral membrane protein
3333	 67.02	0	3976964..3977524	+	186	122879285	-	XOO3720	-	hypothetical protein
3334	 64.85	0	3977561..3978604	+	347	122879286	-	XOO3721	-	putative RNA 2'-O-ribose methyltransferase
3335	 61.95	0	3978926..3980071	-	381	58583345	gfo	XOO3722	-	glucose-fructose oxidoreductase
3336	 63.87	0	3980259..3981008	+	249	58583346	-	XOO3723	-	gluconolactonase precursor
3337	 61.99	0	3980966..3981136	+	56	58583347	-	XOO3724	-	gluconolactonase precursor
3338	 61.96	0	3981219..3981941	+	240	58583348	-	XOO3725	-	hypothetical protein
3339	 64.38	0	3982111..3982548	+	145	58583349	-	XOO3726	-	hypothetical protein
3340	 66.88	0	3982676..3983149	+	157	58583350	-	XOO3727	-	MarR family transcriptional regulator
3341	 61.96	0	3983195..3984022	+	275	58583351	fadB	XOO3728	-	p-hydroxycinnamoyl CoA hydratase/lyase
3342	 65.51	0	3984106..3985575	+	489	58583352	badH	XOO3729	-	aldehyde dehydrogenase
3343	 63.41	0	3985601..3987256	+	551	58583353	-	XOO3730	-	acyl-CoA synthetase
3344	 63.40	0	3987441..3988481	-	346	58583354	pcaQ	XOO3731	-	transcriptional regulator
3345	 64.33	0	3988879..3989775	-	298	58583357	pcaH	XOO3734	-	protocatechuate 4,5-dioxygenase subunit beta
3346	 65.71	0	3990118..3990327	+	69	58583358	vanR	XOO3735	-	GntR family transcriptional regulator
3347	 61.47	0	3990435..3990896	-	153	58583359	-	XOO3736	-	putative transposase
3348	 63.32	0	3990859..3991875	-	338	58583360	-	XOO3737	-	transposase
3349	 63.28	0	3991903..3992433	-	176	58583361	-	XOO3738	-	putative transposase
3350	 66.54	0	3992461..3993273	-	270	58583362	-	XOO3739	-	hydrolase
3351	 68.76	+1	3993401..3994597	-	398	58583363	visC	XOO3740	-	2-octaprenyl-3-methyl-6-methoxy-1,4-benzoquinol hydroxylase
3352	 69.38	+1	3994579..3995793	-	404	58583364	ubiH	XOO3741	-	2-octaprenyl-6-methoxyphenyl hydroxylase
3353	 68.74	+1	3996086..3996664	+	192	122879287	-	XOO3742	-	hypothetical protein
3354	 68.10	+1	3996668..3997225	+	185	58583366	-	XOO3743	-	hypothetical protein
3355	 69.00	+1	3997230..3998171	+	313	58583367	-	XOO3744	-	acetoin utilization family protein
3356	 61.70	0	3998242..4000740	+	832	58583368	ostA	XOO3745	-	organic solvent tolerance protein
3357	 64.44	0	4000737..4002128	+	463	58583369	surA	XOO3746	-	peptidyl-prolyl cis-trans isomerase
3358	 68.00	+1	4002149..4003120	+	323	58583370	pdxA	XOO3747	-	4-hydroxythreonine-4-phosphate dehydrogenase
3359	 64.64	0	4003377..4004165	+	262	58583371	ksgA	XOO3748	-	dimethyladenosine transferase
3360	 66.15	0	4004202..4004585	+	127	58583372	apaG	XOO3749	-	ApaG
3361	 66.04	0	4004614..4005570	+	318	58583373	apaH	XOO3750	-	diadenosine tetraphosphatase
3362	 63.43	0	4005624..4006118	-	164	58583374	folA	XOO3751	-	dihydrofolate reductase type III
3363	 62.01	0	4006469..4007263	-	264	58583375	thyA	XOO3752	-	thymidylate synthase
3364	 63.75	0	4007260..4008150	-	296	58583376	lgt	XOO3753	-	prolipoprotein diacylglyceryl transferase
3365	 66.26	0	4008205..4008696	-	163	58583377	-	XOO3754	-	hypothetical protein
3366	 68.67	+1	4008696..4009592	-	298	58583378	-	XOO3755	-	glycine rich protein
3367	 60.70	0	4009924..4010694	-	256	58583379	-	XOO3756	-	hypothetical protein
3368	 65.31	0	4010658..4011026	-	122	58583380	dgkA	XOO3757	-	diacylglycerol kinase
3369	 65.87	0	4011221..4011724	+	167	122879288	-	XOO3758	-	hypothetical protein
3370	 63.27	0	4011776..4011922	+	48	58583382	-	XOO3759	-	hypothetical protein
3371	 58.06	-1	4012231..4012602	+	123	58583383	-	XOO3760	-	putative transposase
3372	 58.91	-1	4012568..4013044	+	158	58583384	-	XOO3761	-	putative transposase
3373	 64.64	0	4013348..4014679	-	443	58583385	colS	XOO3762	-	two-component system sensor protein
3374	 66.35	0	4014766..4015389	-	207	58583386	colR	XOO3763	-	two-component system regulatory protein
3375	 64.87	0	4015572..4016240	-	222	58583387	tesA	XOO3764	-	acyl-CoA thioesterase I
3376	 69.67	+1	4016350..4016949	+	199	58583388	ftsE	XOO3765	-	ABC transporter ATP-binding protein
3377	 67.91	+1	4016946..4019429	+	827	58583389	-	XOO3766	-	oxidoreductase
3378	 63.89	0	4019581..4020660	+	359	58583390	tauD	XOO3767	-	taurine dioxygenase
3379	 60.75	0	4021428..4021748	+	106	58583392	-	XOO3769	-	ABC transporter substrate binding protein
3380	 65.74	0	4023361..4023468	+	35	58583396	nrtB	XOO3773	-	permease
3381	 57.91	-1	4023551..4023904	+	117	58583397	-	XOO3774	-	hypothetical protein
3382	 64.04	0	4024206..4024853	-	215	58583398	-	XOO3775	-	hypothetical protein
3383	 56.88	-1	4024888..4025490	-	200	122879289	-	XOO3776	-	hypothetical protein
3384	 61.11	0	4026717..4026914	-	65	58583403	phuR	XOO3780	-	outer membrane hemin receptor
3385	 60.57	0	4027339..4027584	-	81	58583404	-	XOO3781	-	hypothetical protein
3386	 66.30	0	4027959..4029047	-	362	58583405	-	XOO3782	-	voltage-gated potassium channel beta subunit
3387	 63.40	0	4031394..4032464	+	356	58583408	rbsK	XOO3785	-	ribokinase
3388	 62.23	0	4033055..4035238	+	727	58583409	-	XOO3786	-	hypothetical protein
3389	 67.27	0	4035348..4036346	+	332	58583410	-	XOO3787	-	hypothetical protein
3390	 64.58	0	4036374..4037093	+	239	58583411	-	XOO3788	-	methyltransferase
3391	 63.78	0	4038535..4039746	+	403	58583414	metK	XOO3791	-	S-adenosylmethionine synthetase
3392	 68.67	+1	4040091..4041689	-	532	58583415	appA	XOO3792	-	phosphoanhydride phosphohydrolase
3393	 61.92	0	4041679..4044435	-	918	58583416	cirA	XOO3793	-	TonB-dependent receptor
3394	 62.40	0	4045514..4046896	+	460
