IslandPath Analysis: Synechococcus sp. JA-3-3Ab



Each circle in the graphic corresponds to a predicted protein-coding ORF in the genome.
Circle colours indicate if an ORF has a higher or lower %G+C than cutoffs you set below
--(default is +/- 3.48 of the mean %G+C).
Strike lines across the circles represent regions with dinucleotide bias above a pre-determined cutoff.
Click on a circle to view a different portion of the table presented below the graph (default is the first 100 ORFs).




A yellow circle indicates its %G+C value is bigger than the high value.
A green circle indicates its %G+C value is bigger than the low value and smaller than the high value.
A pink circle indicates its %G+C value is smaller than the low value.

A strike line across the circles indicates the region has dinucleotide bais above 1 STD DEV.
A black verticle bar indicates a transfer RNA gene lies between the two ORFs.
A purple verticle bar indicates a ribosomal RNA gene lies between the two ORFs.
A deep blue verticle bar indicates both a tRNA and rRNA gene lie between the two ORFs.
A black square indicates the dot is annotated as a transposase.
A black triangle indicates the dot is annotated as an integrase.


Low:  High:    Mean: 60.19   STD DEV: 4.44
Synechococcus sp. JA-3-3Ab, complete genome - 1..2932766
2760 proteins
Pos	%G+C	SD	Location	Strand	Length	PID	Gene	Synonym	Code	Product
1996	 57.48	0	2116444..2117259	-	271	86606739	-	CYA_2099	-	hypothetical protein
1997	 64.45	0	2117544..2118944	-	466	86606740	-	CYA_2100	-	amidase
1998	 57.14	0	2118941..2119129	-	62	86606741	-	CYA_2101	-	hypothetical protein
1999	 61.41	0	2119223..2119831	-	202	86606742	-	CYA_2102	-	hypothetical protein
2000	 65.96	+1	2119978..2120823	-	281	86606743	-	CYA_2103	-	hypothetical protein
2001	 62.65	0	2120988..2121932	+	314	86606744	accD	CYA_2104	-	acetyl-CoA carboxylase subunit beta
2002	 57.33	0	2122212..2122586	+	124	86606745	-	CYA_2105	-	anti-anti-sigma factor
2003	 61.66	0	2122669..2123367	+	232	86606746	-	CYA_2107	-	hypothetical protein
2004	 62.65	0	2123364..2125556	-	730	86606747	-	CYA_2106	-	TrkA domain-containing protein
2005	 53.59	-1	2125625..2125777	-	50	86606748	-	CYA_2108	-	hypothetical protein
2006	 59.69	0	2125969..2127015	+	348	86606749	-	CYA_2109	-	iron ABC transporter substrate-binding protein
2007	 49.36	-2	2127006..2127473	+	155	86606750	-	CYA_2110	-	hypothetical protein
2008	 62.89	0	2127641..2129362	+	573	86606751	-	CYA_2111	-	iron ABC transporter permease
2009	 62.75	0	2129478..2130422	-	314	86606752	atpG	CYA_2112	-	F0F1 ATP synthase subunit gamma
2010	 61.28	0	2130468..2131988	-	506	86606753	atpA	CYA_2113	-	F0F1 ATP synthase subunit alpha
2011	 60.66	0	2132048..2132596	-	182	86606754	atpH	CYA_2114	-	F0F1 ATP synthase subunit delta
2012	 63.35	0	2132613..2133155	-	180	86606755	atpF	CYA_2115	-	F0F1 ATP synthase subunit B
2013	 63.08	0	2133209..2133682	-	157	86606756	-	CYA_2116	-	F0F1 ATP synthase subunit B'
2014	 62.20	0	2133777..2134022	-	81	86606757	atpE	CYA_2117	-	F0F1 ATP synthase subunit C
2015	 58.33	0	2134167..2134298	-	43	86606758	-	CYA_2118	-	hypothetical protein
2016	 54.89	-1	2134252..2134998	-	248	86606759	atpB	CYA_2119	-	F0F1 ATP synthase subunit A
2017	 56.96	0	2135004..2135384	-	126	86606760	-	CYA_2120	-	ATP synthase protein I
2018	 59.18	0	2135901..2136488	+	195	86606761	-	CYA_2121	-	hypothetical protein
2019	 62.22	0	2136485..2136799	+	104	86606762	-	CYA_2122	-	hypothetical protein
2020	 63.15	0	2136813..2138405	-	530	86606763	gpmI	CYA_2123	-	phosphoglyceromutase
2021	 61.33	0	2138613..2139137	-	174	86606764	-	CYA_2124	-	TPR repeat-containing protein
2022	 62.08	0	2139180..2139680	-	166	86606765	dps	CYA_2125	-	DNA starvation/stationary phase protection protein Dps
2023	 66.88	+1	2139799..2141178	-	459	86606766	trmE	CYA_2126	-	tRNA modification GTPase TrmE
2024	 62.05	0	2141368..2143968	+	866	86606767	glgP	CYA_2127	-	alpha-glucan phosphorylase
2025	 63.56	0	2144130..2145191	+	353	86606768	-	CYA_2128	-	TPR repeat-containing protein
2026	 51.94	-1	2145184..2145312	+	42	86606769	-	CYA_2129	-	hypothetical protein
2027	 58.86	0	2145309..2145833	+	174	86606770	ilvH	CYA_2130	-	acetolactate synthase 3 regulatory subunit
2028	 64.17	0	2145879..2146520	+	213	86606771	-	CYA_2131	-	hypothetical protein
2029	 63.45	0	2146709..2147455	-	248	86606772	-	CYA_2132	-	hypothetical protein
2030	 63.90	0	2147594..2148640	+	348	86606773	glk	CYA_2134	-	glucokinase
2031	 65.71	+1	2148619..2148723	-	34	86606774	-	CYA_2133	-	hypothetical protein
2032	 60.24	0	2148726..2149301	-	191	86606775	-	CYA_2135	-	NUDIX family hydrolase
2033	 64.13	0	2149406..2150902	+	498	86606776	trpE	CYA_2136	-	anthranilate synthase component I
2034	 61.38	0	2150921..2151715	+	264	86606777	-	CYA_2137	-	phytanoyl-CoA dioxygenase PhyH family protein
2035	 61.24	0	2151943..2152863	+	306	86606778	chlG	CYA_2138	-	bacteriochlorophyll/chlorophyll a synthase
2036	 61.81	0	2152880..2153023	+	47	86606779	-	CYA_2139	-	hypothetical protein
2037	 64.04	0	2153020..2153475	+	151	86606780	-	CYA_2140	-	hypothetical protein
2038	 61.24	0	2153498..2154880	-	460	86606781	-	CYA_2141	-	sugar  glycoside-pentoside-hexuronide (GPH):cation symporter family protein
2039	 63.64	0	2154964..2156349	-	461	86606782	aspA	CYA_2142	-	aspartate ammonia-lyase
2040	 57.68	0	2156386..2156652	-	88	86606783	-	CYA_2143	-	hypothetical protein
2041	 57.89	0	2156949..2157506	+	185	86606784	infC	CYA_2144	-	translation initiation factor IF-3
2042	 61.72	0	2157522..2157986	+	154	86606785	bcp	CYA_2145	-	bacterioferritin comigratory protein
2043	 64.60	0	2158113..2160044	+	643	86606786	-	CYA_2146	-	serine/threonine protein kinase
2044	 64.57	0	2160096..2161619	-	507	86606787	-	CYA_2147	-	GTP-binding domain-containing protein
2045	 60.22	0	2161837..2162022	-	61	86606788	-	CYA_2148	-	hypothetical protein
2046	 61.58	0	2161892..2162068	-	58	86606789	-	CYA_2149	-	hypothetical protein
2047	 61.93	0	2162126..2162611	-	161	86606790	-	CYA_2150	-	fasciclin domain-containing protein
2048	 64.74	+1	2162830..2164593	+	587	86606791	-	CYA_2151	-	phospholipase D/competence protein ComEA
2049	 63.11	0	2164603..2165586	-	327	86606792	accA	CYA_2152	-	acetyl-CoA carboxylase carboxyltransferase subunit alpha
2050	 61.72	0	2165821..2166285	+	154	86606793	-	CYA_2154	-	hypothetical protein
2051	 59.83	0	2166261..2166743	-	160	86606794	-	CYA_2153	-	hypothetical protein
2052	 61.82	0	2166747..2169575	-	942	86606795	-	CYA_2155	-	sensor histindine kinase/response regulator
2053	 60.83	0	2169520..2170581	-	353	86606796	-	CYA_2156	-	putative methyl-accepting chemotaxis protein, truncation
2054	 55.28	-1	2170715..2171908	+	397	86606797	-	CYA_2158	-	ISSoc1, transposase
2055	 59.08	0	2171905..2172813	-	302	86606798	-	CYA_2157	-	hypothetical protein
2056	 58.44	0	2172824..2173066	-	80	86606799	-	CYA_2159	-	hypothetical protein
2057	 56.10	0	2173121..2173669	-	182	86606800	-	CYA_2160	-	CheW domain-containing protein
2058	 53.07	-1	2173777..2174151	-	124	86606801	-	CYA_2161	-	response regulator
2059	 58.15	0	2174199..2175443	-	414	86606802	-	CYA_2162	-	response regulator
2060	 62.08	0	2175829..2176308	-	159	86606803	-	CYA_2163	-	NUDIX family hydrolase
2061	 62.61	0	2176315..2177547	-	410	86606804	-	CYA_2164	-	hypothetical protein
2062	 59.20	0	2177602..2177802	-	66	86606805	-	CYA_2165	-	hypothetical protein
2063	 49.50	-2	2177856..2180051	-	731	86606806	-	CYA_2166	-	piwi domain-containing protein
2064	 62.39	0	2180122..2180589	-	155	86606807	-	CYA_2167	-	hypothetical protein
2065	 62.31	0	2180637..2181737	-	366	86606808	-	CYA_2168	-	putative lipoprotein
2066	 62.37	0	2181900..2185367	-	1155	86606809	nrdJ	CYA_2169	-	ribonucleoside-triphosphate reductase, adenosylcobalamin-dependent, intein-contatining
2067	 63.48	0	2185700..2186890	+	396	86606810	-	CYA_2170	-	M50B family peptidase
2068	 62.92	0	2187005..2188312	+	435	86606811	-	CYA_2171	-	M16B family peptidase
2069	 64.84	+1	2188312..2189625	+	437	86606812	-	CYA_2172	-	M16 family peptidase
2070	 65.97	+1	2189855..2190574	-	239	86606813	-	CYA_2173	-	hypothetical protein
2071	 60.38	0	2190749..2191273	+	174	86606814	-	CYA_2174	-	acetyltransferase
2072	 65.82	+1	2191277..2191987	+	236	86606815	-	CYA_2175	-	hypothetical protein
2073	 62.92	0	2191994..2192713	-	239	86606816	-	CYA_2176	-	Thf1-like protein
2074	 64.16	0	2192866..2193981	+	371	86606817	proB	CYA_2177	-	gamma-glutamyl kinase
2075	 60.76	0	2193986..2195272	-	428	86606818	-	CYA_2178	-	major facilitator transporter
2076	 61.03	0	2195310..2196320	-	336	86606819	gap-3	CYA_2179	-	glyceraldehyde-3-phosphate dehydrogenase, type I
2077	 65.98	+1	2196566..2197444	-	292	86606820	murI	CYA_2180	-	glutamate racemase
2078	 64.74	+1	2197595..2199466	-	623	86606821	-	CYA_2181	-	N-acetylmuramoyl-L-alanine amidase
2079	 53.77	-1	2199575..2200729	+	384	86606822	-	CYA_2182	-	hypothetical protein
2080	 54.41	-1	2200785..2203076	-	763	86606823	-	CYA_2183	-	nuclease domain-containing protein
2081	 63.37	0	2203378..2204712	-	444	86606824	-	CYA_2184	-	sensor histidine kinase
2082	 64.36	0	2204738..2205343	-	201	86606825	miaE	CYA_2185	-	tRNA-(MS[2]IO[6]A)-hydroxylase
2083	 63.59	0	2205545..2206615	-	356	86606826	-	CYA_2186	-	phospho-2-dehydro-3-deoxyheptonate aldolase
2084	 66.89	+1	2207155..2208510	-	451	86606827	-	CYA_2187	-	RND family efflux transporter MFP subunit
2085	 62.96	0	2208774..2209502	-	242	86606829	sufR	CYA_2189	-	iron-sulfur cluster biosynthesis transcriptional regulator SufR
2086	 56.09	0	2209665..2211101	+	478	86606830	sufB	CYA_2190	-	cysteine desulfurase activator complex subunit SufB
2087	 47.12	-2	2211346..2211744	+	132	86606831	mscL	CYA_2192	-	large conductance mechanosensitive channel protein
2088	 50.00	-2	2211725..2211826	-	33	86606832	-	CYA_2191	-	hypothetical protein
2089	 55.51	-1	2211842..2212657	+	271	86606833	sufC	CYA_2193	-	FeS assembly ATPase SufC
2090	 62.87	0	2212654..2213943	+	429	86606834	sufD	CYA_2194	-	FeS assembly protein SufD
2091	 52.98	-1	2214617..2215069	+	150	86606835	-	CYA_2195	-	AbrB family transcriptional regulator
2092	 64.45	0	2215206..2216606	+	466	86606836	-	CYA_2196	-	hypothetical protein
2093	 60.80	0	2216928..2217353	-	141	86606837	-	CYA_2197	-	nodulation efficiency family protein
2094	 62.08	0	2217437..2217676	-	79	86606838	-	CYA_2198	-	hypothetical protein
2095	 56.08	0	2217819..2218007	+	62	86606839	-	CYA_2200	-	hypothetical protein
60.19	MEAN

4.44	STD DEV
