IslandPathversion 1.0

IslandPath Analysis: Aliivibrio salmonicida LFI1238



Each circle in the graphic corresponds to a predicted protein-coding ORF in the genome. Circle colours indicate if an ORF has a higher or lower %G+C than cutoffs you set below --(default is +/- 3.48 of the mean %G+C). Strike lines across the circles represent regions with dinucleotide bias above a pre-determined cutoff. Click on a circle to view a different portion of the table presented below the graph (default is the first 100 ORFs).
A yellow circle indicates its %G+C value is bigger than the high value. A green circle indicates its %G+C value is bigger than the low value and smaller than the high value. A pink circle indicates its %G+C value is smaller than the low value. A strike line across the circles indicates the region has dinucleotide bais above 1 STD DEV. A black verticle bar indicates a transfer RNA gene lies between the two ORFs. A purple verticle bar indicates a ribosomal RNA gene lies between the two ORFs. A deep blue verticle bar indicates both a tRNA and rRNA gene lie between the two ORFs. A black square indicates the dot is annotated as a transposase. A black triangle indicates the dot is annotated as an integrase. Low: High: Mean: 39.44 STD DEV: 3.11
Aliivibrio salmonicida LFI1238 chromosome 1, complete genome - 1..3325165
2820 proteins
Pos	%G+C	SD	Location	Strand	Length	PID	Gene	Synonym	Code	Product
7	 39.43	0	5554..6225	-	223	209693641	-	VSAL_I0007	-	putative amino-acid ABC transporter, permease protein
8	 39.31	0	6380..7132	-	250	209693642	-	VSAL_I0008	-	putative amino acid ABC transporter,substrate-binding protein
9	 41.01	0	7427..8833	+	468	209693643	dnaA	VSAL_I0009	-	chromosomal replication initiator protein DnaA
10	 40.36	0	8866..9975	+	369	209693644	dnaN	VSAL_I0010	-	DNA polymerase III subunit beta-subunit
11	 41.11	0	9989..11068	+	359	209693645	recF	VSAL_I0011	-	DNA replication and repair protein RecF
12	 42.43	0	11086..13503	+	805	209693646	gyrB	VSAL_I0012	-	DNA gyrase subunit B
13	 40.39	0	14049..15239	-	396	209693647	-	VSAL_I0014	-	transposase
14	 36.21	-1	16295..16642	-	115	209693648	-	VSAL_I0015	-	transposase
15	 37.78	0	16639..16953	-	104	209693649	-	VSAL_I0016	-	transposase
16	 44.44	+1	17172..18809	-	545	209693650	groL1	VSAL_I0017	-	60 kda chaperonin 1
17	 42.01	0	18902..19189	-	95	209693651	groS1	VSAL_I0018	-	10 kDa chaperonin 1
18	 40.62	0	19716..20909	-	397	209693652	-	VSAL_I0019	-	transposase
19	 33.73	-1	21269..21523	+	84	209693653	-	VSAL_I0020	-	hypothetical protein
20	 39.90	0	22530..23489	+	319	209693654	-	VSAL_I0021	-	antirestriction protein
21	 40.70	0	23916..25109	-	397	209693655	-	VSAL_I0022	-	transposase
22	 34.40	-1	25189..26034	+	281	209693656	-	VSAL_I0023	-	metallo-beta-lactamase superfamily protein
23	 35.14	-1	26437..26988	+	183	209693657	cyaB	VSAL_I0024	-	adenylate cyclase
24	 34.97	-1	27382..27747	+	121	209693658	-	VSAL_I0025	-	hypothetical protein
25	 36.05	-1	27776..28180	+	134	209693659	-	VSAL_I0026	-	hypothetical protein
26	 33.46	-1	28436..29215	+	259	209693660	-	VSAL_I0027	-	hypothetical protein
27	 37.42	0	29602..30555	+	317	209693661	-	VSAL_I0028	-	hypothetical protein
28	 40.81	0	30807..31769	-	320	209693662	-	VSAL_I0029	-	transposase
29	 30.93	-2	32166..32456	+	96	209693663	-	VSAL_I0030	-	hypothetical protein
30	 38.56	0	33193..35412	+	739	209693664	-	VSAL_I0031	-	putative cell wall degradation enzyme
31	 30.77	-2	35412..35801	+	129	209693665	-	VSAL_I0032	-	hypothetical protein
32	 32.22	-2	35944..36303	-	119	209693666	-	VSAL_I0033	-	hypothetical protein
33	 31.65	-2	36382..37035	-	217	209693667	-	VSAL_I0034	-	hypothetical protein
34	 40.55	0	37276..38466	-	396	209693668	-	VSAL_I0035	-	transposase
35	 35.94	-1	40119..41000	+	293	209693669	-	VSAL_I0038	-	transposase
36	 40.69	0	41289..42239	+	316	209693670	-	VSAL_I0039	-	transposase
37	 40.54	0	42740..43933	+	397	209693671	-	VSAL_I0040	-	transposase
38	 43.75	+1	44867..46393	+	508	209693672	-	VSAL_I0042	-	putative competence protein
39	 37.82	0	46481..47350	+	289	209693673	-	VSAL_I0043	-	putative acyltransferase
40	 37.18	0	47417..48040	-	207	209693674	dsbA	VSAL_I0044	-	thiol/disulfide interchange protein DsbA precursor
41	 41.87	0	48066..49049	-	327	209693675	rdoA	VSAL_I0045	-	putative phosphotransferase
42	 39.25	0	49108..50526	-	472	209693676	-	VSAL_I0046	-	putative ferredoxin
43	 36.74	0	50752..51015	-	87	209693677	-	VSAL_I0047	-	hypothetical protein
44	 38.04	0	51533..52318	+	261	209693678	-	VSAL_I0048	-	putative sporulation-control protein
45	 36.11	-1	52420..53067	+	215	209693679	hlyIII	VSAL_I0049	-	hemolysin III
46	 40.62	0	53364..54557	-	397	209693680	-	VSAL_I0050	-	transposase
47	 42.38	0	54711..54920	-	69	209693681	cspV	VSAL_I0051	-	cold shock protein
48	 42.27	0	55198..56730	-	510	209693682	ilvA	VSAL_I0052	-	threonine dehydratase
49	 44.87	+1	56735..58207	-	490	209693683	ilvD	VSAL_I0053	-	dihydroxy-acid dehydratase
50	 40.56	0	58234..58482	-	82	209693684	ilvM	VSAL_I0054	-	putative acetolactate synthase small regulatory subunit
51	 40.54	0	59847..61040	+	397	209693685	-	VSAL_I0056	-	transposase
52	 32.77	-2	61632..62159	+	175	209693686	-	VSAL_I0057	-	hypothetical protein
53	 39.35	0	62442..63239	+	265	209693687	-	VSAL_I0058	-	putative ParA chromosome partitioning protein
54	 39.49	0	63236..64210	+	324	209693688	-	VSAL_I0059	-	putative chromosome partitioning protein ParB
55	 41.98	0	64200..64604	+	134	209693689	-	VSAL_I0060	-	hypothetical protein
56	 38.98	0	64789..65160	+	123	209693690	-	VSAL_I0061	-	hypothetical protein
57	 34.85	-1	65851..66444	-	197	209693691	-	VSAL_I0062	-	hypothetical protein
58	 37.82	0	69062..69418	+	118	209693692	-	VSAL_I0065	-	transposase
59	 37.37	0	69494..69790	+	98	209693693	-	VSAL_I0066	-	transposase
60	 36.21	-1	72716..73063	-	115	209693694	-	VSAL_I0069	-	transposase
61	 37.78	0	73060..73374	-	104	209693695	-	VSAL_I0070	-	transposase
62	 44.01	+1	74902..76278	-	458	209693696	trkA	VSAL_I0072	-	Trk system potassium uptake protein TrkA
63	 43.00	+1	76303..77637	-	444	209693697	rsmB	VSAL_I0073	-	ribosomal RNA small subunit methyltransferase B
64	 42.96	+1	77686..78651	-	321	209693698	fmt	VSAL_I0074	-	methionyl-tRNA formyltransferase
65	 40.20	0	78654..79163	-	169	209693699	def	VSAL_I0075	-	peptide deformylase (polypeptide deformylase)
66	 37.85	0	79281..80342	+	353	209693700	-	VSAL_I0076	-	putative cell wall degradation enzyme
67	 43.24	+1	80351..81460	+	369	209693701	smf	VSAL_I0077	-	Smf protein
68	 37.34	0	81463..81936	+	157	209693702	-	VSAL_I0078	-	hypothetical protein
69	 38.60	0	81946..82515	+	189	209693703	yrdD	VSAL_I0079	-	DNA topoisomerase
70	 38.78	0	82555..83673	-	372	209693704	purK	VSAL_I0080	-	phosphoribosylaminoimidazole carboxylase ATPase subunit PurK
71	 43.20	+1	83673..84209	-	178	209693705	purE	VSAL_I0081	-	phosphoribosylaminoimidazole carboxylase catalytic subunit
72	 41.40	0	84360..84917	+	185	209693706	-	VSAL_I0082	-	hypothetical protein
73	 38.81	0	84984..85805	+	273	209693707	aroE	VSAL_I0083	-	shikimate dehydrogenase
74	 35.48	-1	85879..86064	+	61	209693708	-	VSAL_I0084	-	hypothetical protein
75	 34.62	-1	86057..86602	-	181	209693709	-	VSAL_I0085	-	putative transferase
76	 33.56	-1	114812..115696	-	294	209693710	ilvY	VSAL_I0086	-	HTH-type transcriptional regulator, LysR-family
77	 39.06	0	115825..117309	+	494	209693711	ilvC	VSAL_I0087	-	ketol-acid reductoisomerase
78	 33.33	-1	117397..117648	-	83	209693712	-	VSAL_I0088	-	hypothetical protein
79	 40.89	0	117758..120826	-	1022	209693713	-	VSAL_I0089	-	putative integral membrane component of multidrug efflux system
80	 39.30	0	120838..121944	-	368	209693714	-	VSAL_I0090	-	putative multidrug transporter, HlyD family
81	 37.00	0	121963..122562	-	199	209693715	-	VSAL_I0091	-	HTH-type transcriptional regulator, TetR family
82	 39.58	0	122717..124732	+	671	209693716	rep	VSAL_I0092	-	ATP-dependent DNA helicase rep
83	 43.63	+1	124833..125240	-	135	209693717	-	VSAL_I0093	-	cytochrome c
84	 41.76	0	128498..130051	+	517	209693718	-	VSAL_I0095	-	transport protein, extracellular solute-binding protein
85	 40.29	0	130188..131165	+	325	209693719	-	VSAL_I0096	-	binding-protein-dependent transport system,inner membrane component
86	 42.46	0	131168..132109	+	313	209693720	-	VSAL_I0097	-	binding-protein-dependent transport system,inner membrane component
87	 43.26	+1	132347..133927	+	526	209693721	-	VSAL_I0098	-	transporter, BCCT family
88	 40.03	0	134012..134728	-	238	209693722	-	VSAL_I0099	-	putative exonuclease
89	 40.99	0	134738..136618	-	626	209693723	-	VSAL_I0100	-	putative cyclic nucleotide binding protein
90	 41.18	0	136794..137672	+	292	209693724	-	VSAL_I0101	-	hypothetical protein
91	 39.39	0	137656..137919	+	87	209693725	-	VSAL_I0102	-	hypothetical protein
92	 38.81	0	137970..139940	-	656	209693726	-	VSAL_I0103	-	HTH-type transcriptional regulator
93	 42.38	0	140087..140827	-	246	209693727	-	VSAL_I0104	-	hypothetical protein
94	 42.60	+1	140840..141886	-	348	209693728	-	VSAL_I0105	-	hypothetical protein
95	 40.72	0	141927..143063	-	378	209693729	-	VSAL_I0106	-	hypothetical protein
96	 45.62	+1	143122..143772	-	216	209693730	-	VSAL_I0107	-	membrane protein
97	 47.18	+2	143787..144566	-	259	209693731	-	VSAL_I0108	-	membrane protein
98	 28.62	-2	144627..144923	-	98	209693732	-	VSAL_I0109	-	hypothetical protein
99	 45.18	+1	144926..145288	-	120	209693733	-	VSAL_I0110	-	hypothetical protein
100	 31.03	-2	145290..145637	-	115	209693734	-	VSAL_I0111	-	hypothetical protein
101	 36.05	-1	145902..146783	+	293	209693735	-	VSAL_I0112	-	transposase
102	 37.78	0	146904..147218	+	104	209693736	-	VSAL_I0113	-	transposase
103	 36.21	-1	147215..147562	+	115	209693737	-	VSAL_I0114	-	transposase
104	 39.72	0	147634..149121	+	495	209693738	-	VSAL_I0115	-	transposase
105	 36.60	0	149312..151027	-	571	209693739	-	VSAL_I0116	-	hypothetical protein
106	 33.16	-2	151287..151856	-	189	209693740	-	VSAL_I0117	-	putative RNA polymerase sigma factor
39.44	MEAN

3.11	STD DEV
