IslandPathversion 1.0

IslandPath Analysis: Aliivibrio salmonicida LFI1238



Each circle in the graphic corresponds to a predicted protein-coding ORF in the genome. Circle colours indicate if an ORF has a higher or lower %G+C than cutoffs you set below --(default is +/- 3.48 of the mean %G+C). Strike lines across the circles represent regions with dinucleotide bias above a pre-determined cutoff. Click on a circle to view a different portion of the table presented below the graph (default is the first 100 ORFs).
A yellow circle indicates its %G+C value is bigger than the high value. A green circle indicates its %G+C value is bigger than the low value and smaller than the high value. A pink circle indicates its %G+C value is smaller than the low value. A strike line across the circles indicates the region has dinucleotide bais above 1 STD DEV. A black verticle bar indicates a transfer RNA gene lies between the two ORFs. A purple verticle bar indicates a ribosomal RNA gene lies between the two ORFs. A deep blue verticle bar indicates both a tRNA and rRNA gene lie between the two ORFs. A black square indicates the dot is annotated as a transposase. A black triangle indicates the dot is annotated as an integrase. Low: High: Mean: 39.44 STD DEV: 3.11
Aliivibrio salmonicida LFI1238 chromosome 1, complete genome - 1..3325165
2820 proteins
Pos	%G+C	SD	Location	Strand	Length	PID	Gene	Synonym	Code	Product
501	 43.83	+1	596137..596955	-	272	209694135	proC	VSAL_I0542	-	pyrroline-5-carboxylate reductase
502	 38.80	0	596942..597709	-	255	209694136	-	VSAL_I0543	-	membrane protein, related to K+ transport
503	 40.85	0	597733..598770	+	345	209694137	pilT	VSAL_I0544	-	twitching mobility protein PilT, type II/IV secretion system protein
504	 41.10	0	598773..599879	+	368	209694138	pilU	VSAL_I0545	-	twitching motility protein PilU, type II/IV secretion system protein
505	 41.78	0	599983..600408	-	141	209694139	yqgF	VSAL_I0546	-	hypothetical protein
506	 40.43	0	600405..600968	-	187	209694140	-	VSAL_I0547	-	hypothetical protein
507	 41.34	0	601042..602028	-	328	209694141	gshB	VSAL_I0548	-	glutathione synthetase
508	 39.21	0	602012..602743	-	243	209694142	-	VSAL_I0549	-	hypothetical protein
509	 40.06	0	602822..603535	-	237	209694143	-	VSAL_I0550	-	endonuclease I precursor
510	 41.77	0	603626..604111	-	161	209694144	-	VSAL_I0551	-	putative metallopeptidase, SprT family
511	 42.60	+1	604227..605381	-	384	209694145	metK	VSAL_I0552	-	S-adenosylmethionine synthetase
512	 33.33	-1	605512..605667	-	51	209694146	-	VSAL_I0553	-	hypothetical protein
513	 46.05	+2	605768..607765	+	665	209694147	tktA	VSAL_I0554	-	transketolase 1
514	 39.02	0	607905..608924	+	339	209694148	epd	VSAL_I0555	-	erythrose-4-phosphate dehydrogenase
515	 42.87	+1	609091..610254	+	387	209694149	pgk	VSAL_I0556	-	phosphoglycerate kinase
516	 43.73	+1	610409..611485	+	358	209694150	fbaA	VSAL_I0557	-	fructose-bisphosphate aldolase class II
517	 42.29	0	611726..612976	-	416	209694151	srmB	VSAL_I0558	-	ATP-dependent RNA helicase SrmB
518	 34.75	-1	613065..613769	-	234	209694152	-	VSAL_I0559	-	hypothetical protein
519	 40.33	0	614058..615371	+	437	209694153	-	VSAL_I0560	-	branched chain amino acid transport system II carrier protein
520	 40.08	0	615500..616018	-	172	209694154	fldB	VSAL_I0561	-	flavodoxin 2
521	 39.42	0	616155..617057	+	300	209694155	xerD	VSAL_I0562	-	tyrosine recombinase XerD
522	 39.51	0	617137..617913	+	258	209694156	dsbC	VSAL_I0563	-	thiol/disulfide interchange protein DsbC precursor
523	 41.15	0	617993..619732	+	579	209694157	recJ	VSAL_I0564	-	single-stranded-DNA-specific exonuclease RecJ
524	 41.97	0	621111..622616	+	501	209694158	lysU	VSAL_I0566	-	lysyl-tRNA synthetase, heat inducible
525	 39.31	0	623013..624350	+	445	209694159	-	VSAL_I0567	-	sigma-54 interacting regulatory protein
526	 41.26	0	624417..625085	-	222	209694160	mutH	VSAL_I0568	-	DNA mismatch repair protein MutH
527	 41.33	0	625679..626191	+	170	209694161	nudH	VSAL_I0569	-	(di)nucleoside polyphosphate hydrolase
528	 39.61	0	626228..628489	+	753	209694162	ptsP	VSAL_I0570	-	phosphoenolpyruvate-protein phosphotransferase PtsP
529	 40.05	0	628490..629293	+	267	209694163	-	VSAL_I0571	-	integral membrane protein
530	 40.14	0	629304..630155	+	283	209694164	lgt	VSAL_I0572	-	prolipoprotein diacylglyceryl transferase
531	 39.51	0	630234..631091	+	285	209694165	thyA	VSAL_I0573	-	thymidylate synthase
532	 41.01	0	631160..632305	-	381	209694166	nptA	VSAL_I0574	-	sodium-dependent phosphate pump
533	 37.26	0	632642..633583	+	313	209694167	nhaR	VSAL_I0575	-	transcriptional activator protein NhaR (sodium/proton antiporter regulator protein)
534	 33.97	-1	633619..633930	+	103	209694168	hlyU	VSAL_I0576	-	transcriptional activator HlyU
535	 44.83	+1	634052..634312	-	86	209694169	rpsT	VSAL_I0577	-	30S ribosomal protein S20
536	 39.29	0	634534..636093	+	519	209694170	mviN	VSAL_I0578	-	virulence factor MviN homolog
537	 39.23	0	636184..637116	+	310	209694171	ribF	VSAL_I0579	-	riboflavin biosynthesis protein RibF
538	 42.08	0	637153..640011	+	952	209694172	ileS	VSAL_I0580	-	isoleucyl-tRNA synthetase
539	 40.50	0	640011..640526	+	171	209694173	lspA	VSAL_I0581	-	lipoprotein signal peptidase
540	 37.96	0	640621..641052	+	143	209694174	fkpB	VSAL_I0582	-	FkbP-type 16 kDa peptidyl-prolyl cis-trans isomerase
541	 40.53	0	641077..642021	+	314	209694175	ispH	VSAL_I0583	-	4-hydroxy-3-methylbut-2-enyl diphosphate reductase
542	 42.10	0	642091..642900	+	269	209694176	dapB	VSAL_I0584	-	dihydrodipicolinate reductase
543	 44.42	+1	643459..644613	+	384	209694177	carA	VSAL_I0585	-	carbamoyl-phosphate synthase small chain
544	 43.86	+1	644631..647861	+	1076	209694178	carB	VSAL_I0586	-	carbamoyl-phosphate synthase large chain
545	 39.01	0	647963..649372	-	469	209694179	dacB	VSAL_I0587	-	penicillin-binding protein 4 precursor
546	 42.12	0	649514..650515	-	333	209694180	ompU	VSAL_I0588	-	major outer membrane protein OmpU
547	 39.24	0	651098..651571	+	157	209694181	greA	VSAL_I0589	-	transcription elongation factor GreA
548	 35.69	-1	651666..651962	-	98	209694182	-	VSAL_I0590	-	putative RNA-binding protein
549	 41.11	0	652081..652710	+	209	209694183	rrmJ	VSAL_I0591	-	ribosomal RNA large subunit methyltransferase J (cell division protein FtsJ)
550	 41.70	0	652796..654778	+	660	209694184	hflB	VSAL_I0592	-	cell division protein FtsH
551	 40.17	0	654843..655676	+	277	209694185	folP	VSAL_I0593	-	dihydropteroate synthase
552	 40.73	0	655733..657070	+	445	209694186	glmM	VSAL_I0594	-	phosphoglucosamine mutase
553	 40.54	0	657222..657554	+	110	209694187	secG	VSAL_I0595	-	protein-export membrane protein SecG (preprotein translocase band subunit)
554	 39.25	0	657962..658417	+	151	209694188	-	VSAL_I0596	-	hypothetical protein
555	 41.13	0	658434..659921	+	495	209694189	nusA	VSAL_I0597	-	transcription elongation protein NusA
556	 42.71	+1	659945..662620	+	891	209694190	-	VSAL_I0598	-	translation initiation factor IF-2
557	 41.67	0	662734..663141	+	135	209694191	rbfA	VSAL_I0599	-	ribosome-binding factor A
558	 41.07	0	663141..664097	+	318	209694192	truB	VSAL_I0600	-	tRNA pseudouridine synthase B
559	 42.22	0	664260..664529	+	89	209694193	rpsO	VSAL_I0601	-	30S ribosomal protein S15
560	 44.23	+1	664832..666988	+	718	209694194	pnp	VSAL_I0602	-	polyribonucleotide nucleotidyltransferase
561	 36.79	0	667099..668082	+	327	209694195	nlpI	VSAL_I0603	-	lipoprotein NlpI precursor
562	 37.09	0	668165..669043	-	292	209694196	-	VSAL_I0604	-	putative peptidase
563	 41.42	0	669053..670054	-	333	209694197	-	VSAL_I0605	-	putative peptidase
564	 37.50	0	670270..672309	-	679	209694198	-	VSAL_I0606	-	putative signaling protein
565	 36.22	-1	672524..673042	+	172	209694199	-	VSAL_I0607	-	hypothetical protein
566	 39.29	0	673032..673535	+	167	209694200	-	VSAL_I0608	-	putative acetyltransferase
567	 32.08	-2	673678..673836	+	52	209694201	-	VSAL_I0609	-	hypothetical protein
568	 33.73	-1	673857..674105	-	82	209694202	-	VSAL_I0610	-	hypothetical protein
569	 38.06	0	674232..674633	+	133	209694203	-	VSAL_I0611	-	DNA polymerase III, psi subunit
570	 38.26	0	674623..675069	+	148	209694204	rimI	VSAL_I0612	-	ribosomal-protein-alanine acetyltransferase
571	 42.88	+1	675187..676767	+	526	209694205	prfC	VSAL_I0613	-	peptide chain release factor 3 (RF-3)
572	 36.05	-1	676846..676992	+	48	209694206	-	VSAL_I0614	-	hypothetical protein
573	 36.55	0	676973..677749	+	258	209694207	-	VSAL_I0615	-	putative DNase
574	 43.61	+1	677973..679256	+	427	209694208	-	VSAL_I0616	-	putative sodium-dependent nucleoside transporter protein
575	 39.30	0	679393..680700	+	435	209694209	-	VSAL_I0617	-	transposase
576	 40.00	0	681014..681223	+	69	209694210	-	VSAL_I0618	-	hypothetical protein
577	 42.86	+1	681508..682284	+	258	209694211	deoC	VSAL_I0619	-	deoxyribose-phosphate aldolase
578	 42.19	0	682400..683731	+	443	209694212	deoA	VSAL_I0620	-	thymidine phosphorylase
579	 42.51	0	683742..684962	+	406	209694213	deoB	VSAL_I0621	-	phosphopentomutase
580	 37.33	0	685836..686435	-	199	209694214	smp	VSAL_I0623	-	peripheral membrane protein
581	 40.45	0	686566..687534	+	322	209694215	serB	VSAL_I0624	-	phosphoserine phosphatase
582	 37.81	0	687588..689933	-	781	209694216	-	VSAL_I0625	-	hypothetical protein
583	 43.12	+1	690051..691430	+	459	209694217	radA	VSAL_I0626	-	DNA repair protein RadA (dna repair protein sms)
584	 43.31	+1	691624..693708	+	694	209694218	fusA	VSAL_I0627	-	elongation factor G (EF-G)
585	 35.90	-1	693819..694052	-	77	209694219	-	VSAL_I0628	-	hypothetical protein
586	 39.20	0	694165..695442	-	425	209694220	codA	VSAL_I0629	-	cytosine deaminase
587	 42.26	0	695453..696706	-	417	209694221	codB	VSAL_I0630	-	cytosine permease
588	 38.64	0	697136..698812	-	558	209694222	-	VSAL_I0631	-	putative AMP-binding acetyl-CoA synthetase
589	 41.71	0	699029..701596	-	855	209694223	mutS	VSAL_I0632	-	DNA mismatch repair protein MutS
590	 42.77	+1	701705..702202	+	165	209694224	-	VSAL_I0633	-	putative competence-damaged protein
591	 39.66	0	702343..703386	+	347	209694225	recA	VSAL_I0634	-	protein RecA (recombinase A)
592	 42.28	0	703629..706211	+	860	209694226	alaS	VSAL_I0635	-	alanyl-tRNA synthetase
593	 37.26	0	706221..707390	+	389	209694227	lysC	VSAL_I0636	-	aspartokinase 2
594	 43.28	+1	707472..707672	+	66	209694228	csrA	VSAL_I0637	-	carbon storage regulator
595	 40.87	0	709310..709561	+	83	209694229	-	VSAL_I0638	-	oxaloacetate decarboxylase 1, subunit gamma
596	 41.50	0	709599..711386	+	595	209694230	-	VSAL_I0639	-	oxaloacetate decarboxylase 2, subunit alpha
597	 41.11	0	711398..712528	+	376	209694231	-	VSAL_I0640	-	oxaloacetate decarboxylase, beta subunit
598	 38.66	0	712625..713056	+	143	209694232	-	VSAL_I0641	-	inner membrane protein
599	 39.08	0	713065..715917	+	950	209694233	-	VSAL_I0642	-	exported pepdidase, putative zinc protease
600	 38.31	0	716044..717609	+	521	209694234	gshA	VSAL_I0643	-	glutamate--cysteine ligase
39.44	MEAN

3.11	STD DEV
