IslandPath Analysis: Yersinia pestis Angola



Each circle in the graphic corresponds to a predicted protein-coding ORF in the genome.
Circle colours indicate if an ORF has a higher or lower %G+C than cutoffs you set below
--(default is +/- 3.48 of the mean %G+C).
Strike lines across the circles represent regions with dinucleotide bias above a pre-determined cutoff.
Click on a circle to view a different portion of the table presented below the graph (default is the first 100 ORFs).




A yellow circle indicates its %G+C value is bigger than the high value.
A green circle indicates its %G+C value is bigger than the low value and smaller than the high value.
A pink circle indicates its %G+C value is smaller than the low value.

A strike line across the circles indicates the region has dinucleotide bais above 1 STD DEV.
A black verticle bar indicates a transfer RNA gene lies between the two ORFs.
A purple verticle bar indicates a ribosomal RNA gene lies between the two ORFs.
A deep blue verticle bar indicates both a tRNA and rRNA gene lie between the two ORFs.
A black square indicates the dot is annotated as a transposase.
A black triangle indicates the dot is annotated as an integrase.


Low:  High:    Mean: 47.59   STD DEV: 5.21
Yersinia pestis Angola, complete genome - 1..4504254
3832 proteins
Pos	%G+C	SD	Location	Strand	Length	PID	Gene	Synonym	Code	Product
1	 42.86	0	270..710	-	146	162418840	mioC	YpAngola_A0001	-	flavodoxin
2	 41.56	-1	803..1264	-	153	162418440	-	YpAngola_A0002	-	DNA-binding transcriptional regulator AsnC
3	 45.52	0	1434..2426	+	330	162419901	asnA	YpAngola_A0003	-	asparagine synthetase AsnA
4	 47.72	0	2525..3991	-	488	162419510	-	YpAngola_A0004	-	hypothetical protein
5	 46.78	0	3995..5533	-	512	162419989	-	YpAngola_A0005	-	regulatory ATPase RavA
6	 45.80	0	5807..7675	+	622	162419440	kup	YpAngola_A0006	-	potassium transport protein Kup
7	 48.10	0	7880..8299	+	139	162420591	rbsD	YpAngola_A0007	-	D-ribose pyranase
8	 50.05	0	8350..9276	+	308	162420036	rbsK	YpAngola_A0008	-	ribokinase
9	 46.46	0	9496..10920	-	474	162421578	-	YpAngola_A0009	-	major facilitator transporter
10	 44.06	0	11000..11689	-	229	162418549	-	YpAngola_A0011	-	GntR family transcriptional regulator
11	 44.22	0	12058..12204	-	48	162419929	-	YpAngola_A0012	-	hypothetical protein
12	 49.55	0	17956..19164	+	402	162420022	-	YpAngola_A0017	-	IS285, transposase
13	 40.86	-1	19222..19779	-	185	162420544	mobB	YpAngola_A0018	-	molybdopterin-guanine dinucleotide biosynthesis protein B
14	 43.54	0	19752..20339	-	195	162420127	mobA	YpAngola_A0019	-	molybdopterin-guanine dinucleotide biosynthesis protein A
15	 41.11	-1	20493..20762	+	89	162421614	-	YpAngola_A0020	-	hypothetical protein
16	 46.50	0	20853..21839	+	328	162421169	-	YpAngola_A0021	-	serine/threonine protein kinase
17	 42.15	-1	21867..22490	+	207	162418848	dsbA	YpAngola_A0022	-	periplasmic protein disulfide isomerase I
18	 47.48	0	22982..25780	+	932	162418335	polA	YpAngola_A0023	-	DNA polymerase I
19	 46.39	0	26188..26838	-	216	162420510	-	YpAngola_A0024	-	GTPase EngB
20	 48.50	0	27583..28149	+	188	162420098	-	YpAngola_A0025	-	hypothetical protein
21	 47.74	0	28332..29705	+	457	162421654	hemN	YpAngola_A0026	-	coproporphyrinogen III oxidase
22	 52.65	0	29759..31171	-	470	162421177	ntrC	YpAngola_A0027	-	nitrogen regulation protein NR(I)
23	 49.24	0	31179..32228	-	349	162418453	ntrB	YpAngola_A0028	-	nitrogen regulation protein NR(II)
24	 46.08	0	32466..32975	-	169	162421858	-	YpAngola_A0029	-	IS1541, transposase
25	 50.78	0	33192..34601	-	469	162418660	glnA	YpAngola_A0030	-	glutamine synthetase
26	 45.83	0	34959..35102	+	47	162418157	-	YpAngola_A0031	-	hypothetical protein
27	 48.96	0	35162..36985	+	607	162420145	typA	YpAngola_A0032	-	GTP-binding protein TypA/BipA
28	 44.16	0	37307..37897	+	196	162419585	-	YpAngola_A0033	-	phosphatase
29	 48.02	0	37994..38878	+	294	162419107	rbn	YpAngola_A0034	-	ribonuclease BN
30	 48.86	0	38885..39322	+	145	162420883	dtd	YpAngola_A0035	-	D-tyrosyl-tRNA deacylase
31	 51.90	0	39396..40871	-	491	162420449	-	YpAngola_A0036	-	transposase
32	 50.87	0	41141..42064	+	307	162421692	-	YpAngola_A0037	-	acetyltransferase domain-containing protein
33	 48.30	0	42199..43908	-	569	162421773	-	YpAngola_A0038	-	asmA family protein
34	 50.43	0	44056..45441	-	461	162418696	yicE	YpAngola_A0039	-	xanthine permease
35	 50.04	0	45679..46893	+	404	162418297	gltS	YpAngola_A0040	-	sodium/glutamate symport carrier protein
36	 51.63	0	47259..49340	-	693	162419548	recG	YpAngola_A0041	-	ATP-dependent DNA helicase RecG
37	 49.64	0	49341..50033	-	230	162419568	trmH	YpAngola_A0042	-	tRNA guanosine-2'-O-methyltransferase
38	 48.93	0	50039..52147	-	702	162419160	spoT	YpAngola_A0043	-	bifunctional (p)ppGpp synthetase II/ guanosine-3',5'-bis pyrophosphate 3'-pyrophosphohydrolase
39	 51.45	0	52167..52442	-	91	162421700	rpoZ	YpAngola_A0044	-	DNA-directed RNA polymerase subunit omega
40	 46.31	0	52497..53120	-	207	162420259	gmk	YpAngola_A0045	-	guanylate kinase
41	 48.60	0	53548..55224	+	558	162420613	ligA2	YpAngola_A0046	-	NAD-dependent DNA ligase LigB
42	 48.50	0	56263..57126	-	287	162421145	-	YpAngola_A0048	-	hypothetical protein
43	 51.32	0	57253..57969	+	238	162421592	rph	YpAngola_A0049	-	ribonuclease PH
44	 46.08	0	58094..58603	+	169	162420108	-	YpAngola_A0050	-	IS1541, transposase
45	 50.77	0	58846..59493	+	215	162420480	pyrE	YpAngola_A0051	-	orotate phosphoribosyltransferase
46	 47.91	0	59628..60224	-	198	162419507	-	YpAngola_A0052	-	nucleoid occlusion protein
47	 49.12	0	60346..60801	-	151	162419944	dut	YpAngola_A0053	-	deoxyuridine 5'-triphosphate nucleotidohydrolase
48	 47.67	0	60782..62113	-	443	162418631	coaBC	YpAngola_A0054	-	bifunctional phosphopantothenoylcysteine decarboxylase/phosphopantothenate synthase
49	 45.44	0	62193..62861	+	222	162421088	radC	YpAngola_A0055	-	DNA repair protein RadC
50	 50.63	0	63124..63360	+	78	162421887	rpmB	YpAngola_A0056	-	50S ribosomal protein L28
51	 39.29	-1	63372..63539	+	55	162420005	rpmG	YpAngola_A0057	-	50S ribosomal protein L33
52	 48.89	0	63622..64431	+	269	162418456	mutM	YpAngola_A0058	-	formamidopyrimidine-DNA glycosylase
53	 46.25	0	64437..64916	-	159	162421465	coaD	YpAngola_A0059	-	phosphopantetheine adenylyltransferase
54	 46.62	0	64913..65695	-	260	162421414	-	YpAngola_A0060	-	lipopolysaccharide core biosynthesis glycosyl transferase
55	 50.55	0	65696..66973	-	425	162420891	kdtA	YpAngola_A0061	-	3-deoxy-D-manno-octulosonic-acid transferase
56	 50.72	0	67393..68358	-	321	162420814	rfaC	YpAngola_A0062	-	ADP-heptose:LPS heptosyl transferase I
57	 51.74	0	68358..69422	-	354	162420304	rfaF	YpAngola_A0063	-	ADP-heptose:LPS heptosyltransferase II
58	 45.12	0	69453..70385	-	310	162418166	rfaD	YpAngola_A0064	-	ADP-L-glycero-D-mannoheptose-6-epimerase
59	 50.08	0	70601..71842	+	413	162418575	kbl	YpAngola_A0065	-	2-amino-3-ketobutyrate coenzyme A ligase
60	 48.15	0	71852..72877	+	341	162419275	tdh	YpAngola_A0066	-	L-threonine 3-dehydrogenase
61	 50.18	0	73973..75325	-	450	162420738	-	YpAngola_A0068	-	hypothetical protein
62	 50.13	0	75353..76900	-	515	162421119	gpmI	YpAngola_A0069	-	phosphoglyceromutase
63	 45.06	0	77297..77731	+	144	162421581	-	YpAngola_A0070	-	rhodanese domain-containing protein
64	 51.41	0	77850..78098	+	82	162418373	grxC	YpAngola_A0071	-	glutaredoxin 3
65	 48.43	0	78186..78662	+	158	162419011	secB	YpAngola_A0072	-	preprotein translocase subunit SecB
66	 51.57	0	78662..79681	+	339	162419751	gpsA	YpAngola_A0073	-	NAD(P)H-dependent glycerol-3-phosphate dehydrogenase
67	 49.70	0	79944..80768	+	274	162420074	cysE	YpAngola_A0074	-	serine acetyltransferase
68	 49.08	0	80891..81379	-	162	162420361	-	YpAngola_A0075	-	RNA methyltransferase
69	 50.73	0	81568..82389	+	273	162421118	-	YpAngola_A0076	-	regulatory protein ada (regulatory protein of adaptative response)
70	 52.79	0	82471..83493	+	340	162421422	-	YpAngola_A0077	-	transposase for insertion sequence
71	 50.38	0	83493..84272	+	259	162421756	-	YpAngola_A0078	-	transposase/IS protein
72	 49.89	0	84640..86016	-	458	162419902	cpxA	YpAngola_A0080	-	two-component sensor protein
73	 49.93	0	86013..86711	-	232	162420224	cpxR2	YpAngola_A0081	-	DNA-binding transcriptional regulator CpxR
74	 46.63	0	86885..87373	+	162	162420508	-	YpAngola_A0082	-	periplasmic stress adaptor protein CpxP
75	 46.33	0	87830..88006	+	58	162421116	-	YpAngola_A0083	-	hypothetical protein
76	 50.94	0	88051..89010	+	319	162421671	-	YpAngola_A0084	-	hypothetical protein
77	 48.50	0	89572..90474	+	300	162418138	fieF	YpAngola_A0087	-	ferrous iron efflux protein F
78	 47.15	0	90692..91675	+	327	162419444	pfkA	YpAngola_A0088	-	6-phosphofructokinase
79	 46.06	0	91896..92885	+	329	162419271	-	YpAngola_A0089	-	sulfate transporter subunit
80	 48.23	0	93135..93953	-	272	162419581	-	YpAngola_A0090	-	hypothetical protein
81	 44.61	0	94029..95456	-	475	162420835	-	YpAngola_A0091	-	divalent anion:Na+ symporter (DASS) family protein
82	 54.06	+1	95522..96235	-	237	162421101	ligK	YpAngola_A0092	-	hypothetical protein
83	 51.63	0	96232..96969	-	245	162419643	-	YpAngola_A0093	-	hypothetical protein
84	 50.08	0	97106..98341	+	411	162419827	-	YpAngola_A0094	-	LysR family substrate binding transcriptional regulator
85	 48.96	0	98573..99340	-	255	162420847	tpiA	YpAngola_A0095	-	triosephosphate isomerase
86	 45.13	0	99469..100104	-	211	162420311	-	YpAngola_A0096	-	hypothetical protein
87	 51.95	0	100252..100686	+	144	162421850	-	YpAngola_A0097	-	hypothetical protein
88	 52.07	0	101008..101754	-	248	162421018	fpr	YpAngola_A0098	-	ferredoxin-NADP reductase
89	 51.80	0	101909..102964	-	351	162421185	glpX	YpAngola_A0099	-	fructose 1,6-bisphosphatase II
90	 52.03	0	103156..104679	-	507	162418727	glpK	YpAngola_A0100	-	glycerol kinase
91	 50.88	0	104856..105704	-	282	162418263	glpF	YpAngola_A0101	-	glycerol uptake facilitator protein
92	 42.92	0	106332..106571	+	79	162418438	-	YpAngola_A0102	-	hypothetical protein
93	 45.69	0	106779..107288	-	169	162418550	-	YpAngola_A0103	-	IS1541, transposase
94	 50.00	0	107414..107599	+	61	162419770	-	YpAngola_A0104	-	hypothetical protein
95	 43.83	0	107608..109722	-	704	162419349	-	YpAngola_A0105	-	bacteriocin ABC transporter, ATP-binding/permease protein
96	 39.13	-1	109715..111007	-	430	162420638	-	YpAngola_A0106	-	MFP family transporter
97	 45.83	0	111220..111459	+	79	162420640	-	YpAngola_A0107	-	hypothetical protein
98	 29.33	-2	111634..111783	+	49	162420207	-	YpAngola_A0108	-	hypothetical protein
99	 53.37	+1	112140..112673	+	177	162421432	-	YpAngola_A0109	-	hypothetical protein
100	 47.53	0	112790..113275	-	161	162418907	rraA	YpAngola_A0110	-	ribonuclease activity regulator protein RraA
47.59	MEAN

5.21	STD DEV
